KAWASAKI FS06

Dettagli robot

Kawasaki FS06 is mostly for medium payload applications including press tending, loading and unloading of parts, handling, polishing, arc welding, spot welding, measurement and assembly. It can support weights of up to 6 kg with very high speed and accuracy. The FX 06's reach of 1102 mm provides a good working envelope while maintaining a wonderful repeatability of 0.05 mm.

It has six axes that aid in increasing flexibility and this together with a slim design minimises dead space. Compactness is further enhanced by a vertically aligned body and one motor robot pedestal.

Products in F series have long held reputation for the axes' high torque whereby they can make rotation speeds of more than 700 degrees per second. Customers can also enjoy the flexibility of choosing between different arm combinations depending on their desired reach and payload requirements.

Applicazioni Robot

• Stampaggio
• Carico e scarico dei pezzi
• Manipolazione di parti
• Lucidatura
• Saldatura ad arco
• Saldatura a punti
• Misurazione
• Assemblaggio di parti

Robot Info:

• Maximum Load of Robot: 6 Kg.
• Maximum Reach Horizontal: 1102mm.
• Repeatability: 0,05mm.
• Controller: C

Robot Motion Speed:

• Axis 1: 240º/s
• Axis 2: 240º/s
• Axis 3: 250º/s
• Axis 4: 430º/s
• Axis 5: 430º/s
• Axis 6: 720º/s

Robot Applications:

• Arc welding
• Handling of parts
